Product ID: ASP-001
Brand: ADDER Technolog...
A control suite which transforms ADDERLink INFINITY (ALIF) extenders into a digital matrix solution. Using standard IP infrastructure, the AIM routes any user station to any computer attached to the network without any compromises to video quality or control. It allows co–operative sharing of computers and multicasting of video to any destination.
Physical Design
Robust metal construction
• (L)210mm/8.3” x (W)215mm/8.5” x (D)40mm/1.6”
• Weight: 1.8kg/4lbs
Power supply
• External power: 12VDC, 5A
• Typical power consumption: 20W
• BTU: 68.24BTU/hr
Operating temperature
• 0 to 40ºC/32 to 104ºF
Storage temperature
• Storage temperature: 0 to 60ºC/32 to 140 ºF
• Altitude: < 2000m xss=removed> • 10-90% (non-condensing)
Mean Time Between Failure (MTBF)
• 77,500 hrs
• Telcordia SR332 Issue 4 March 2016 Calculated @55ºC
Ethernet
• 1GbE with 10/100/1000 support via 2x SFP and 1x 8p8c
Approvals
• CE, FCC
